Author: FAIRCHILD Semiconductor
Year of publication: 2003
What it is?
The paper presents a catalog of bipolar power transistors manufactured by fairchild semiconductor. The following types of transistors are described: General Purpose Transistors; Darlington Transistors; Switching Transistors; Horizontal Deflection Output Transistors; Dynamic Focus Transistors; Audio & Car Amp Output Transistors; Anti-Saturation Transistors;
Catalog structure
1. General Purpose Transistors
- DPAK
- D2PAK
- SOT-223
- IPAK
- TO-126
- TO-220
- TO-220F
2. Darlington Transistors
- DPAK
- IPAK
- TO-126
- TO-220
- TO-220F
- TO-3P
- TO-3PF
3. Switching Transistors
- DPAK
- D2PAK
- TO-92
- TO-126
- TO-220
- TO-220F
- TO-3P
- TO-3PF
4. Horizontal Deflection Output Transistors
- TO-220F
- TO-3PF
- TO-264
5. Dynamic Focus Transistors
- TO-126
- TO-220
- TO-220F
6. Audio & Car Amp Output Transistors
- TO-3P
- TO-3PF
- TO-264
7. Anti-Saturation Transistors
- DPAK
- IPAK
- TO-126
- TO-220
- Packages
- Surface Mount (DPAK, D2PAK)
- Through-Hole (TO-92, IPAK, TO-126, TO-220)
- Through-Hole (TO-220F, TO-3P, TO-3PF, TO-264)
