Electronic devices

Electronic devices - Oscillators and PLL circuits

Reading time: 3 minute

Author: Thomas L. Floyd
Publisher: Teora
Year of publication: 2003

About the book:

Whatever profession you are preparing for, it will require a lot of hard work, and electronics is no exception.

This book is a complete manual on electronic devices and circuits and their applications. The well-represented sections on troubleshooting and practical applications make an important connection between theory and practice.

The topics covered are divided into two main categories. Chapters 1… 11 are dedicated to discrete devices and circuits, and chapters 12… 18 refer mainly to linear integrated circuits. To make the most of this book, you need to read, judge, solve problems, and work in the lab for a long time. You should not expect all the notions and working methods to seem clear to you from the beginning. Follow in detail the solution of each example and then perform the complementary exercise. Answer all the summary questions and check yourself by consulting the answers at the end of each chapter. If you have not understood a certain example or you cannot answer one of the questions, repeat that section until you have accumulated all the necessary knowledge and only then move on to the next section.

The self-assessment tests with multiple choice answers at the end of each chapter are a satisfactory way to check if you have understood and retained all the issues in that chapter.


CHAPTER 1. Introduction to semiconductors

1-1. The structure of the atom
1-2. Semiconductors, conductors and insulators
1-3. Covalent bonds
1-4. Semiconductor conduction
1-5. N-type and p-type semiconductors
1-6. Junction pn
1-7. Polarization of the junction pn
1-8. The current-voltage characteristics of the pn junction
1-9. diode

CHAPTER 2. Applications of diodes

2-1. Mono-alternating rectifiers
2-2. Double alternating rectifiers
2-3. Filters for power supplies
2-4. Limiters and diode axis circuits
2-5. Voltage multipliers
2-6. Diode catalogs
2-8. Practical application

CHAPTER 3. Special use diodes

3-1. Zener diode
3-2. Applications of the Zener diode
3-3. Varactor diode
3-4. Optical diodes
3-5. Other types of diodes
3-6. Troubleshooting
3-7. Practical application

CHAPTER 4. Bipolar transistors with junctions

4-1. Transistor structure
4-2. Transistor operating principle
4-3. Transistor characteristics and parameters
4-4. Transistor amplification function
4-5. Transistor switching function
4-6. Encapsulation of transistors and identification of terminals
4-7. Troubleshooting
4-8. Practical application

CHAPTER 5. Transistor bias circuits

5-1. Static operating point
5-2. Base polarization from VCC
5-3. Polarization of the emitter from the separate voltage source
5-4. Polarization with resistive divider
5-5. Polarization with reaction in the collector
5-6. Troubleshooting
5-7. Practical application

CHAPTER 6. Small signal amplifiers with bipolar transistors

6-1. Operation of small signal amplifiers
6-2. Equivalent AC circuits of the transistor
6-3. Amplifiers with common emitter
6-4. Amplifiers with common collector
6-5. Common base amplifiers
6-6. Multi-stage amplifiers
6-7. Troubleshooting
6-8. Practical application

CHAPTER 7. Power amplifiers

7-1. Class A amplifiers
7-2. Counter time amplifiers in classes B and ab
7-3. Class C amplifiers
7-4. Troubleshooting
7-5. Practical application

CHAPTER 8. Field effect transistors and their polarization

8-1. Field effect transistor with junction gate (jfet)
8-2. The characteristics and parameters of a jfet
8-3. Polarization of jfet devices
8-4. Metal-oxide-semiconductor field effect transistor (mosfet)
8-5. The characteristics and parameters of a mosfet
8-6. Polarization of MOSfet devices
8-7. Troubleshooting
8-8. Practical application

CHAPTER 9. Small Signal Amplifiers with Field Effect Transistors (FET)

9-1. Operation of small signal amplifiers with fetus
9-2. Fetal amplification
9-3. Amplifiers with common source
9-4. Common drain amplifiers
9-5. Common gate amplifiers
9-6. Troubleshooting
9-7. Practical application

CHAPTER 10. Frequency response of amplifiers

10-1. General notions
10-2. decibel
10-3. Amplifier response to low frequencies
10-4. Miller capacity
10-5. Amplifier response to high frequencies
10-6. The global frequency response of amplifiers
10-7. Frequency response of FET amplifiers
10-8. Frequency response of multi-stage amplifiers
10-9. Frequency response measurement
10-10. Practical application

CHAPTER 11. Thyristors and other devices

11-1. Docka Shockley
11-2. thyristor
11-3. Thyristor applications
11-4. The double gate thyristor
11-5. The deacon and the triac
11-6. Junction transistor
11-7. Programmable junction transistor (tup)
11-8. phototransistor
11-9. The photo thyristor
11-10. Optical couplers
11-11. Practical application

CHAPTER 12. Operational amplifiers

12-1. Presentation of operational amplifiers
12-2. Differential amplifier
12-3. AO parameters
12-4. Negative reaction
12-5. AO configurations with negative reaction
12-6. Effects of adverse reaction on AO impedances
12-7. Compensation of polarization current and offset voltage
12-8. Troubleshooting
12-9. Practical application

CHAPTER 13. Frequency response, stability and compensation ao

13-1. General notions
13-2. The answer in the open loop
13-3. The answer in a closed loop
13-4. Positive reaction and stability
13-5. Compensation
13-6. Practical application

CHAPTER 14. Functional circuits with operational amplifiers

14-1. Comparators
14-2. Adding amplifiers
14-3. Integration and derivation circuits
14-4. Troubleshooting
14-5. Practical application

CHAPTER 15. Other circuits with operational amplifiers

15-1. Measuring amplifiers
15-2. Isolation amplifiers
15-3. Operational Transconducting Amplifiers (AOT)
15-4. Logarithmic and antilogarithmic amplifiers
15-5. Converters and other AO circuits
15-6. Practical application

CHAPTER 16. Active filters

16-1. Answers to basic filter types
16-2. Filter response patterns
16-3. Active filters go down
16-4. Active pass-up filters
16-5. Active bandpass filters
16-6. Active stop-band filters
16-7. Measuring the filter response
16-8. Practical application

CHAPTER 17. PLL oscillators and circuits

17-1. oscillator
17-2. The principles of the oscillator
17-3. Oscillators with RC reaction circuits
17-4. Oscillators with LC reaction circuits
17-5. Non-sinusoidal oscillators
17-6. Timing circuit 555 as an oscillator
17-7. PLL circuit
17-8. Practical application

CHAPTER 18. Voltage stabilizers

18-1. Voltage stabilization
18-2. Elementary series stabilizers
18-3. Elementary parallel stabilizers
18-4. Elementary switching stabilizers
18-5. Integrated voltage stabilizers
18-6. Applications of integrated voltage stabilizers
18-7. Practical application


A. Table with standardized resistor values
B. Deduction of some formulas
C. It was a catalog
Answers to self-assessment tests
Answers to problems with odd numbers
